SPECIFICATIONS
| Model NAME | UNI FAN SL 120 | UNI FAN SL 140 |
|---|---|---|
| Model NO. | UF-SL120-1B BLACK / UF-SL120-3B White / UF-SL120-1W WHITE / UF-SL120-3W WHITE | UF-SL140-1B BLACK / UF-SL140-1W WHITE |
| Fan Dimension | 120 X 120 X 25 ( mm ) | 140 X 140 X25 ( mm ) |
| Fan Speed | 800~1900RPM | 500~1500RPM |
| Max. Air Pressure | 2.54mmH2O | 1.67mmH2O |
| Max. Air Flow | 58.54CFM | 70.5 CFM |
| Acoustical Noise (Min-Max.) | 31dB(A) Max | 30dB(A) Max |
| Locked Current | >= 50mA | >= 10mA |
| Bearing Type | Fluid Dynamic Bearing(FDB) | Fluid Dynamic Bearing(FDB) |
| Connector Type (single pack) | 1 x 4 Pin (PWM) + 1 x 3 Pin (ARGB) | 1 x 4 Pin (PWM) + 3 Pin (ARGB) |
| Connector Type (3 pack / 2 PACK) | 1 x 4 Pin (PWM) + 3 x SM 3 Pin (ARGB) | 1 x 4 Pin (PWM) + 2 x SM 3 Pin (ARGB) |
| Start-up Voltage | DC 6.0V | DC 6.0V |
| Input Power | 5.16Watt | 3.6W |
| Rated Voltage | DC 12V (FAN) / 5V (LED) | DC 12V (FAN) / 5V (LED) |
| Rated Current | 0.18A (FAN) / 0.6A (LED) | 0.1A (FAN) / 0.34A (LED) |
| Warranty | 2 year | 2 year |
